NEXEDGE 800 MHz Digital & FM Portable Radio
Kenwood NX-420 Features
- 806 - 870 MHz (1W/3W)
- 260 CH-GID / 128 Zones (LCD Model)
- 64 CH-GID / 4 Zones (Non LCD Model)
- 12-Key Keypad Model
- 8 Character Alphanumeric Aliases
- Function / Status LCD Icons
- Transmit / Busy / Call Alert / Warn LED
- On / Off Volume Knob
- 16-Position Selector
- 4 Front PF Keys
- 2 Side PF Keys
- Emergency / AUX Key
- Built-in Motion Sensor
- 500 mW Speaker Audio
- Zone / CH Number Voice Announcement
- KMC-48GPS Speaker Mic Option
- KPG-141D Windows® FPU
- Flash Firmware Upgrading
- MIL-STD-810 C/D/E/F/G
- IP54/55 Dust & Water Intrusion
- PC Serial Interface
- SDM Manual Input*1
- Transparent Data Mode*1
Digital General
- NXDN® Digital Air Interface
- AMBE+2™ VOCODER
- 6.25 & 12.5 kHz Channels
- Over-the-Air Alias
- Over-the-Air Programming
- Paging Call
- Emergency Call
- All Group Call
- Status Messaging*1 *2
- Remote Stun / Kill*1
- Remote Check*1
- Short & Long Data Messages*1
- GPS Location with Voice*1
- NXDN® Scrambler Included
Digital-Conventional Mode
- 64 Radio Access Numbers (RAN)
- Individual & Group Selective Call*3
- Mixed FM / Digital Operation
- Conventional IP Networks
- Site Roaming
Digital-Trunking Mode
- Individual Private Call
- Group Call & Broadcast Call
- Telephone Interconnect
- Transmission Trunked Mode*4
- Message Trunked Mode*4
- Call Queuing with Priority*4
- Late Entry (UID & GID)*4
- 4 Priority Monitor ID’s*4
- Remote Re-Grouping*1
- Failsoft Mode
Multi-Site IP Network Compatible
- 60,000 GIDs / UIDs
- Wide Area Group Call
- Auto Roaming Registration
- Group Registration
Scan
- Single Zone / Multi-Zone / List Scan
- Single Priority Scan (Conventional)
FM Modes-General
- 25 & 12.5 kHz Channels
- NPSPAC Channels
- Conventional & LTR® Zones
- FleetSync® / II, MDC-1200, DTMF*3
- QT / DQT (Conventional Zones only)*3
- Voice Inversion Scrambler (16 Codes)
FleetSync/ II FM
- PTT ID ANI / Caller ID*3
- Selective /Group Call*3
- Emergency, Status & Text Messages*1
MDC-1200
- PTT ID ANI / Caller ID*3
- Emergency, Radio Check & Inhibit
- Requires compatible software application (e.g. KAS-10) or console hardware.
- Non LCD Model -Pre-programmed key operation
- Non LCD Model -Some screen / key-based functions are not available.
- These trunked features are primarily system programming and operational dependent. Priority Monitor also requires NX subscriber settings.
